MikroTik RB260GSP 5-Port GbE 4x PoE-Out SwOS Smart Switch SFP Desktop

The RB260GSP is a small-form-factor smart switch designed for SOHO and light commercial environments. It features five 10/100/1000 Mbps Gigabit Ethernet ports and one SFP cage for fibre or SFP-based uplinks, housed in a compact plastic desktop case. Switching is handled by the Atheros QCA8337 switch chip, which delivers non-blocking Layer 2 throughput across all ports. The unit runs MikroTik SwOS (SwitchOS), an operating system purpose-built for MikroTik switch products, providing a simple browser-based management interface without the complexity of a full router OS.

Passive PoE Output

One of the RB260GSP's defining features is its ability to deliver passive PoE output on Ethernet ports 2 through 5. The switch passes through the same voltage that is applied to the unit, over the data lines only, allowing it to power compatible passive PoE devices such as wireless access points, IP cameras, and small CPEs directly from the switch. The low-voltage PoE-out current limit per port is 1A, with a maximum combined PoE-out output of 2A across all active PoE ports. This makes power budgeting straightforward for small deployments.

SFP Port with DDMI

The single SFP port supports DDMI (Digital Diagnostics Monitoring Interface), allowing administrators to monitor real-time optical transceiver data such as signal strength, temperature, and voltage directly through SwOS. This is useful in installations where the RB260GSP is uplinked to a fibre backbone or a distant switch via an SFP module.

Powering Options

The RB260GSP accepts power via two inputs: a DC jack (11–30V) and a passive PoE input on Ether1 (11–30V), giving flexibility for standard adapter use or passive PoE-in from an upstream injector or switch. Maximum power consumption under full load with all PoE ports active is 53W; without any PoE output load, the switch itself consumes just 5W. A 24V 2.5A power adapter and an IEC power cord are included in the box. Cooling is fully passive, making the unit completely silent in operation.

SwOS Management

The device runs MikroTik SwOS, which is pre-installed and licenced — no additional purchase is required. SwOS provides browser-based Layer 2 switch management covering VLAN configuration, port mirroring, link aggregation, STP/RSTP, bandwidth limiting, and per-port statistics. It is accessible via a simple web interface and is well suited to users who need smart switch functionality without the full RouterOS learning curve.

Monitoring

The RB260GSP includes a PCB temperature monitor and a voltage monitor, giving administrators visibility into the switch's thermal and electrical health through the SwOS interface.

Build and Suitability

The desktop plastic enclosure measures 113 × 139 × 28mm, making it compact enough to sit on a desk, shelf, or inside a small equipment cabinet. Its IP20 rating is appropriate for standard indoor environments. With a tested operating temperature range of -20°C to +70°C and an MTBF of approximately 100,000 hours at 25°C, it is built for reliable, long-term deployment in typical office and commercial settings.

Use Cases

The RB260GSP is well suited to small offices and retail locations needing Gigabit switching with integrated PoE for access points or cameras, home networks requiring a managed smart switch with fibre uplink capability, and any deployment where a compact, silent, fanless switch with passive PoE-out is preferred over a larger managed switch.

Key Specifications at a Glance

• Product Code: CSS106-1G-4P-1S
• Switch Chip: QCA8337
• Gigabit Ethernet Ports: 5 × 10/100/1000 Mbps
• SFP Port: 1 (with DDMI support)
• PoE Out: Passive PoE on Ether2–Ether5 (same voltage as input, data lines only)
• PoE-Out Current Limit: 1A per port; 2A total maximum output
• PoE In: Passive PoE 11–30V on Ether1
• DC Input: 11–30V via DC jack
• Max Power Consumption: 53W (5W without attachments)
• Included Power Supply: 24V 2.5A power adapter + IEC cord
• Operating System: MikroTik SwOS
• Storage: 128KB FLASH
• Cooling: Passive (fanless)
• Monitoring: PCB temperature monitor, voltage monitor
• MTBF: ~100,000 hours at 25°C
• Tested Ambient Temperature: -20°C to +70°C
• IP Rating: IP20
• Dimensions: 113 × 139 × 28mm
• Certifications: CE, EAC, RoHS
• Included Parts: 24V 2.5A power adapter, IEC cord
