MikroTik S+RJ10 r3 6-Speed 10G RJ45 SFP+ Copper Module
zoom_out_map
chevron_left chevron_right

MikroTik S+RJ10 – 6-Speed 10G RJ45 SFP+ Copper Module (r3, up to 100 m)

6-speed RJ45 module that brings 10M, 100M, 1G, 2.5G, 5G and 10G Ethernet over familiar twisted-pair copper to any MikroTik SFP+ port — no optical fiber required. The current r3 revision is based on the Marvell MV-CUX3610M, draws 1.5 W max, supports 10GBASE-T links up to 100 m over Cat6/7 and jumbo frames on all advertised speeds.

US$65.00 Tax excluded

US$65.00 Tax excluded

Back-Order, Contact us for the ETA
new_releases Back-Order, delivery 2-3 days
US/Canada
We only offer IC Certified products. For international products, contact us.
Please note!
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.

The MikroTik S+RJ10 is a unique 6-speed RJ45 module that opens up a whole world of high-speed connectivity, delivering up to 10 Gbps over regular twisted-pair cables in products that have SFP+ ports. Any MikroTik device with SFP+ ports can be used without installing optical fiber — just plug in the S+RJ10 and your network is ready for 10 Gbps and the next generation of RJ45 hardware.

Six Speeds in One Module

The S+RJ10 supports 10BASE-T, 100BASE-T, 1000BASE-T, 2.5GBASE-T, 5GBASE-T and 10GBASE-T, so it can connect to legacy gear today and to multi-gig and 10G copper equipment tomorrow — all from the same SFP+ port.

Revision r3 – Lower Power, Longer Reach

The current r3 revision (identified by “/r3” at the end of the serial number) is based on the Marvell MV-CUX3610M and brings several improvements over the earlier r2: lower power consumption of 1.5 W max, 10GBASE-T links up to 100 m over Cat6/7 cable, and jumbo frame support on all advertised speeds.

Maximum Supported Cable Length

  • 10M / 100M / 1G / 5G: up to 100 m over Cat5e/6
  • 2.5G: up to 100 m over Cat5e/6 UTP or STP
  • 10G (r3): up to 100 m over Cat6/7
  • 10G (r2): up to 30 m over Cat6/7
  • Same lengths apply S+RJ10 to S+RJ10, S+RJ10 to other brands, and S+RJ10 to a standard Ethernet port

Compatible MikroTik Devices

Designed for MikroTik devices with SFP+ ports, including the CCR1072-1G-8S+, CCR1036 series, CCR1016-12S-1S+, CCR1009 series, CRS317-1G-16S+RM, CRS210-8G-2S+IN, CRS212-1G-10S-1S+IN and CRS326/CSS326 series. For detailed model compatibility, check the MikroTik wiki.

Key Specifications at a Glance:

  • Product Code: S+RJ10
  • Format: SFP+
  • Connector: RJ45
  • Speeds: 10M / 100M / 1G / 2.5G / 5G / 10G
  • Chipset (r3): Marvell MV-CUX3610M
  • Max Power Consumption (r3): 1.5 W
  • 10GBASE-T reach (r3): up to 100 m over Cat6/7
  • Jumbo frames: supported on all advertised speeds (r3)

Important Revision Notice:

Earlier r2 units (serial ending in “/r2”) are based on the Marvell 88X3310P, draw up to 2.7 W, support 10GBASE-T up to 30 m and can only be used in SFP+ ports. If your installation depends on 10G links longer than 30 m, please confirm the revision with us before ordering.

If you would like to test the device, our return period is 7 days. The product must be returned in good condition with all original parts, accessories, and retail packaging. Incomplete or damaged returns may be subject to a restocking fee of up to 30%.

MikroTik
S+RJ10
New
4752224005106
S+RJ10
Product code
S+RJ10
Format
SFP+
Connector
RJ45
Data Rate
10M / 100M / 1G / 2.5G / 5G / 10G
Distance
100m (r3, 10GBASE-T over Cat6/7)
Max Power consumption
1.5 W
Size of RAM
0 KB
Storage size
256 KB
Storage type
FLASH
chipset
Marvell MV-CUX3610M (r3)
Cable Type
Cat5e/6 up to 5G, Cat6/7 for 10G
