CCR2004-1G-12S+2XS
The MikroTik CCR2004-1G-12S+2XS is a powerful connectivity router featuring 12x 10G SFP+ ports, 2x 25G SFP28 ports, and 4GB ECC RAM. It offers exceptional single-core performance for seamless SFP, SFP+, and SFP28 management.
We only offer IC Certified products. For international products, contact us.
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.
The MikroTik CCR2004-1G-12S+2XS is the ultimate connectivity router for managing SFP, SFP+, and SFP28 interfaces. Equipped with 12x 10G SFP+ ports, 2x 25G SFP28 ports, and a Gigabit Ethernet port, this router provides unparalleled flexibility for modern networking needs. Powered by a high-performance CPU, it delivers the best single-core performance in MikroTik's lineup, achieving up to 3.4Gbps in single tunnel and BGP feed processing.
Built for reliability, the CCR2004-1G-12S+2XS features dual redundant power supplies, ensuring minimal downtime and continuous operation. Its compact design and advanced port configuration make it a versatile addition to professional networking setups, capable of handling 10G, 25G, and even 40G networks when paired with MikroTik’s multiport switches. With 4GB ECC RAM and RouterOS v7, this router provides exceptional stability and performance, making it an indispensable tool for ISPs, enterprises, and advanced networking environments.
Ethernet test results
| CCR2004-1G-12S+2XS | AL32400 All port test (CCR2004-1G-12S+2XS) | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 3174.4 | 38549.7 | 6626.7 | 27142.9 | 10972.5 | 5969 |
| Bridging | 25 bridge filter rules | 1763.6 | 21417 | 1794.3 | 7349.6 | 1773.9 | 965 |
| Routing | none (fast path) | 3138.7 | 38116 | 5790.3 | 23717.1 | 11159.7 | 6070.9 |
| Routing | 25 simple queues | 1849.3 | 22458 | 1876.9 | 7688 | 1883.8 | 1024.8 |
| Routing | 25 ip filter rules | 1177.8 | 14303.7 | 1185.1 | 4854.3 | 1169.7 | 636.3 |
- Product code
- CCR2004-1G-12S+2XS
- CPU core count
- 4
- CPU nominal frequency
- 17000 MHz
- Operating System
- RouterOS
- Size of RAM
- RouterOS v6 1792MB ECC / RouterOS v7 4GB ECC
- Storage size
- 128 MB, NAND
- Max Power consumption
- 49W
- Dimensions
- 443 x 224 x 44 mm
- Number of AC inputs
- 2
- Operating Temperature
- -20°C to +60°C tested
- Input Voltage
- AC power supply 100 - 240 V
- Certification
- CE/RED, EAC, ROHS
- RAM type
- DDR4
- Number of 10G SFP+ ports
- 12
- Number of 1G Ethernet ports
- 1
- Number of 25G SFP28 ports
- 2
