RB260GSP
The MikroTik RB260GSP is a compact smart switch with 5x Gigabit Ethernet ports, PoE-out on ports 2-5, 1 SFP cage, and SwOS for easy management.
We only offer IC Certified products. For international products, contact us.
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.
The MikroTik RB260GSP is a SOHO smart switch designed for small office and home networks. It features 5x Gigabit Ethernet ports, with PoE-out on ports 2-5 for powering PoE-capable devices using the same voltage as applied to the unit. Additionally, it includes 1 SFP cage for fiber connectivity. Powered by an Atheros switch chip, the RB260GSP runs on SwOS, an operating system tailored for MikroTik switches, offering advanced features such as VLAN configuration, port-to-port forwarding, traffic mirroring, and bandwidth control. Compact and versatile, it is perfect for networks requiring power and connectivity in a single solution.
Switching results
| CSS106-1G-4P-1S | |||||||
|---|---|---|---|---|---|---|---|
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Switching | Non blocking Layer 2 throughput | 487.6 | 5,922.0 | 1,409.8 | 5,774.4 | 8,928.6 | 4,571.4 |
| Switching | Non blocking Layer 2 capacity | 487.6 | 11,844.0 | 1,409.8 | 11,548.9 | 8,928.6 | 9,142.9 |
| Switching | Non blocking Layer 1 throughput | 487.6 | 6,000.0 | 1,409.8 | 6,000.0 | 8,928.6 | 6,000.0 |
| Switching | Non blocking Layer 1 capacity | 487.6 | 12,000.0 | 1,409.8 | 12,000.0 | 8,928.6 | 12,000.0 |
- Product code
- CSS106-1G-4P-1S
- Architecture
- RISC
- Operating System
- MikroTik SwOS
- Storage size
- 128 KB
- Storage type
- FLASH
- Tested ambient temperature
- -25℃ to +65℃
- Number of DC inputs
- 2 (DC jack, PoE-IN)
- DC jack input Voltage
- 11-30 V
- Max Power consumption
- 5W
- PoE in
- Passive PoE
- PoE in input Voltage
- 11-30 V
- PoE out
- Passive PoE
- 10/100/1000 Ethernet ports
- 5
- Dimensions
- 113x139x28mm
- SFP DDMI
- Yes
- SFP ports
- 1
- Voltage Monitor
- Yes
- PCB temperature monitor
- Yes
