MikroTik ATL 5G R16 – Rugged 5G LTE Outdoor Router with eSIM Support
zoom_out_map
chevron_left chevron_right
Contact us for back-order

ATL 5G R16

Rugged 5G outdoor router with eSIM, LTE Cat 20 modem, high-gain 16 dBi antenna, and RouterOS v7. Reliable Gigabit speeds even in remote or signal-congested locations. Built to thrive outdoors.

US$349.00 Tax excluded

US$349.00 Tax excluded

block Contact us for back-order
US/Canada
We only offer IC Certified products. For international products, contact us.
Please note!
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.

The MikroTik ATL 5G R16 delivers fast and reliable internet in even the most remote or signal-congested areas. Featuring a built-in 5G LTE CAT20 modem, high-gain directional antenna, eSIM support, and durable IP66-rated housing, ATL is perfect for rural deployments or off-grid use. Its flexible power options, RouterOS v7, and Gigabit Ethernet ensure professional-grade networking, stability, and performance in any environment.

Key Features:

  • 5G + LTE CAT 20 Modem: Up to 4.2 Gbps download, 900 Mbps upload speeds.

  • High-Gain 16 dBi Directional Antenna: Exceptional range and reliability.

  • Built-in MikroTik eSIM + Micro SIM Slot: Immediate connectivity with flexible options.

  • Dual-Core ARM CPU + 512 MB RAM: Smooth routing and high throughput.

  • Wi-Fi 6 Performance Over 5 GHz: Maximum responsiveness.

  • RouterOS v7: Advanced networking, VPN, security, and container support.

  • PoE-In + Gigabit Ethernet: Simplified setup with power and data over one cable.

  • IP66 Rugged Enclosure: Snow-resistant and dust-tight, ideal for harsh weather.

Deployment Solutions:

  • Remote and Rural Access: Ideal for countryside homes, farms, and cabins needing Gigabit 5G connections.

  • Failover & Backup: Ensures constant connectivity during outages.

  • Mobile Work Units: Reliable network for field trucks, emergency services, or remote offices.

  • Off-grid Installations: Compatible with solar and battery-powered systems.

Industries Benefiting:

  • Agriculture & Farming – remote monitoring, irrigation systems.

  • Public Safety & Emergency Services – deploy fast, reliable networks on the go.

  • Energy & Utilities – supports oil rigs, wind farms, and other isolated locations.

  • Construction & Mining – deploy networks at new or temporary sites.

MikroTik
ATL 5G R16
New
4752224008305
Product code
ATLGM&RG520F-EU
CPU architecture
ARM 64bit
CPU
Dual-Core 88F3720 800 MHz
Operating System
RouterOS v7, License level 3
Size of RAM
512 MB
Storage size
32 MB Flash
Max Power consumption
10 W
Max power consumption without attachments
10 W
3G Category
R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
3G bands
1 (2100MHz) / 5 (850MHz) / 8 (900MHz)
Dimensions
311 x 311 x 179 mm
Number of SIM slots
1 Micro SIM, eSIM
LTE Category
20 (2.0 Gbps Downlink, 200 Mbps Uplink)
LTE FDD bands
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz) / 32 (1500 MHz)
LTE TDD bands
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) / 42 (3500MHz) / 43 (3700MHz)
MIMO DL
4x4
TAC
86945405
Input Voltage
12-56 V
Antenna gain
16 dBi
Number of 1G Ethernet ports
1
LTE modem
R11mL-RG520F
Power adapter nominal voltage
24 V
Power adapter nominal current
0.8 A
5G NSA FDD bands
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800 MHz) / 28 (700 MHz)
5G SA FDD bands
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800 MHz) / 28 (700 MHz)
5G SA TDD bands
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) / 75 (1500 MHz) / 76 (1500 MHz) / 77 (3700 MHz) / 78 (3500 MHz)
Number of M.2 SATA slots
1
5G SA Category
4.2 Gbps Downlink, 900 Mbps Uplink
5G NSA Category
5.0 Gbps Downlink, 650 Mbps Uplink
5G NSA TDD bands
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) / 75 (1500 MHz) / 76 (1500 MHz) / 77 (3700 MHz) / 78 (3500 MHz)
Operating temperature
-40°C to +70°C
DC input
PoE-In
PoE-In
802.3af/at
