CCR1036-8G-2S+
1U rackmount, 8x Gigabit Ethernet, 2xSFP+ cages, LCD, 36 cores x 1.2GHz CPU, 4GB RAM, 41.5mpps fastpath, Up to 28Gbit/s throughput, RouterOS L6, Dual PSU
US/Canada
We only offer IC Certified products. For international products, contact us.
We only offer IC Certified products. For international products, contact us.
Please note!
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.
Discontinued
Our fastest router has now become even better - the new CCR1036-8G-2S+ now has two SFP+ ports for 10G interface support (SFP+ module available separately). It uses the same 36 core Tilera CPU as our other CCR1036 model, and delivers the same performance.
The device comes in a 1U rackmount case, has two SFP+ ports, eight Gigabit ethernet ports and serial console port.
The new version of CCR1036-8G-2S+ has onboard 4GB of RAM, onboard M.2 PCIe 4x slot, full size USB slot and dual PSU for redundancy!
Supports both SFP (1.25G) and SFP+ (10G) modules
- Product code
- CCR1036-8G-2S+
- Architecture
- TILE
- CPU core count
- 36
- CPU nominal frequency
- 1.2 GHz
- Operating System
- RouterOS v6
- Size of RAM
- 2 GB
- Storage size
- 128 MB
- Storage type
- NAND
- Tested ambient temperature
- -20C .. +60C
- Max Power consumption
- 44W
- Number of AC inputs
- 2
- AC input range
- 100-240
- SFP DDMI
- Yes
- SFP+ ports
- 2
- Serial port
- RS232
- Number of USB ports
- 1
- USB Power Reset
- Yes
- USB slot type
- microUSB type AB
- Max USB current (A)
- 1
- CPU temperature monitor
- Yes
- Current Monitor
- Yes
- Voltage Monitor
- Yes
- PCB temperature monitor
- Yes
